Sharing the same Dell logo, the same Intel Gen 13 CPU, and falling within the 40-50 million VND price range, yet Dell XPS 17 9730 and Dell Precision 5680 serve two distinctly different user groups. Notably, much information online is currently confusing: the XPS 17 9730 actually does not have an OLED option, and the Precision 5680 (a workstation) is actually over half a kilogram lighter than the XPS 17. Such seemingly small details can lead you to choose the wrong machine if you only skim through the specifications. Below is a comparison table based on the actual configurations available at Hung Phat Laptop, along with an analysis of each difference to help you choose the right machine for architectural graphics work.
Dell XPS 17 9730 vs. Dell Precision 5680 Technical Specifications Comparison
Both series share the Intel Raptor Lake-H (45W) CPU platform but differ significantly in three key areas: GPU type, display options, and port design.
| Specifications | Dell XPS 17 9730 | Dell Precision 5680 |
|---|---|---|
| Screen Size | 17 inch (16:10) | 16 inch (16:10) |
| CPU | Core i7-13700H / i9-13900H (45W) | Core i7-13700H / i7-13800H / i9-13900H (45W, vPro) |
| GPU | GeForce RTX 4050 / 4060 / 4070 / 4080 TGP limited to 60W for all SKUs | RTX A1000 6GB / RTX 2000 Ada 8GB / RTX 3500 Ada 12GB ISV Certified Drivers |
| RAM | Up to 64GB DDR5 4800MHz 2x SODIMM slots, upgradable | Up to 64GB, depending on SKU: LPDDR5 6000MHz onboard or DDR5 SODIMM |
| Display | FHD+ (1920×1200) or UHD+ (3840×2400) IPS panel, 500 nits No OLED option | WUXGA (1920×1200) IPS or WQUXGA (3840×2400) OLED Supports PremierColor |
| Storage | Up to 8TB (2x M.2 PCIe Gen 4) | Up to 4TB (M.2 PCIe Gen 4) |
| Ports | 4× Thunderbolt 4, 3.5mm, SD card Includes USB-A + HDMI adapter in box | 2× Thunderbolt 4, 1× USB-C 3.2 Gen 2, HDMI 2.0b, USB-A, 3.5mm |
| Battery | 97 Wh | 66 Wh or 99.5 Wh (depending on configuration) |
| Weight | 2.44 kg | 1.91 kg |
| Wi-Fi | Wi-Fi 6 (AX211) | Wi-Fi 6E (AX211) |
| Reference Price | 40 - 50 million | 40 - 50 million |
Looking at the table, there are several noteworthy points that many comparison articles often overlook. First, all GeForce GPUs on the XPS 17 9730 are limited to a 60W TGP, which is significantly lower than gaming laptops with the same card name (usually 100-140W). An RTX 4070 60W on the XPS 17 will be noticeably weaker than an RTX 4070 140W on a 16-inch gaming laptop. Second, the Precision 5680 is half a kilogram lighter than the XPS 17 (1.91 vs 2.44 kg), contradicting the common perception that "workstations are heavier than ultrabooks."
Consumer GPU or Workstation GPU: which should you choose for architectural graphics?
This is the most important difference between the two series and is a factor that directly affects the daily workflow experience with architectural software.
GeForce RTX on the XPS 17 uses Game Ready drivers, which are optimized by NVIDIA for gaming and general content creation applications like Premiere Pro, DaVinci Resolve, and Photoshop. For Revit, AutoCAD, or SketchUp with light to medium workloads, GeForce still performs well. However, when opening large Revit projects (over 500MB) or rendering V-Ray with many complex materials, Game Ready drivers can sometimes encounter display errors or unexpected crashes because these drivers have not undergone ISV testing with engineering software.
RTX Professional Ada on the Precision 5680 uses ISV certified drivers. Autodesk, Dassault, McNeel (Rhino), and other major architectural software companies test and certify stability on these drivers before release. This does not mean the Precision is always faster in raw benchmarks. In fact, a GeForce RTX 4060 might score higher in 3DMark than an RTX 2000 Ada. However, in a real-world working environment, when you have been running Revit for 8 consecutive hours, driver stability is more important than a few percentage points of rendering performance.
Additionally, some Precision 5680 configurations with the RTX 3500 Ada or higher also support ECC VRAM, which helps reduce calculation errors when processing complex 3D models. This is a feature not available on any GeForce card.
500 nits IPS or OLED: which to choose for architectural work?
One thing to note: the XPS 17 9730 does not have an OLED option. The highest option for the XPS 17 is the UHD+ (3840×2400) IPS panel with 500 nits brightness. This is a high-quality panel with 100% sRGB coverage, suitable for design work requiring moderate color accuracy.
In contrast, the Precision 5680 offers a 3840×2400 OLED option with Dell's PremierColor technology. OLED displays provide an almost infinite contrast ratio, absolute blacks, and wide DCI-P3 coverage, which is a clear advantage when you need to check renders with complex dark and light areas or when presenting perspectives to clients.
However, OLED also has drawbacks for architectural work:
- Risk of burn-in if displaying static interfaces (Revit or AutoCAD toolbars) for long periods
- Maximum brightness is often lower than IPS in full-screen white mode, which is a disadvantage when working outdoors or in brightly lit rooms
- Glossy panel, which has more reflections than matte IPS
If your primary work involves technical drawing in AutoCAD or Revit with static interfaces for many hours, the IPS on the XPS 17 is actually more suitable. If your work leans towards rendering and presenting images to clients, the OLED on the Precision 5680 offers a significantly better visual experience.
Should you buy the Dell XPS 17 9730 or the Dell Precision 5680?
Instead of a general conclusion, here are suggestions based on specific work groups:
| Requirement | Recommended Machine | Reason |
|---|---|---|
| Using AutoCAD, SketchUp, Photoshop, and occasional light rendering | XPS 17 9730 | Spacious 17-inch screen for drawings, 2x M.2 slots for easy storage upgrades, long-lasting 97Wh battery |
| Running large Revit projects, continuous V-Ray / Enscape rendering, 3D simulation | Precision 5680 | Stable ISV drivers for prolonged heavy workloads, Ada Generation GPU optimized for engineering software |
| Frequent travel, meetings at construction sites, presenting renders to clients | Precision 5680 | Lighter than the XPS 17 by over half a kilogram (1.91 vs 2.44 kg), better OLED for presentations, built-in HDMI + USB-A without needing an adapter |
| Need the largest screen possible, limited use of external monitors | XPS 17 9730 | 17 inch vs 16 inch; while the 1-inch difference seems small, the actual display area differs by about 12% |
| 4K video editing combined with graphic design, occasional gaming | XPS 17 9730 | GeForce RTX supports NVENC/CUDA well for Premiere, DaVinci Resolve, and runs games smoother than workstation cards |
Another point to consider: if you need to connect to an external monitor or projector during meetings, the Precision 5680 has a built-in HDMI 2.0b and USB-A port, ready to use. The XPS 17 only has Thunderbolt 4, so all connections require an adapter. Dell includes an adapter in the box, but it is still something easily forgotten when rushing to a meeting.
Both series are available at Hung Phat Laptop. You can visit us to experience the difference in weight, screen quality, and keyboard firsthand before making your decision.
Frequently Asked Questions (FAQ)
1. Does the XPS 17 9730 have an OLED screen?
No. The XPS 17 9730 only comes with IPS panels, with the highest option being UHD+ (3840×2400) 500 nits. Between these two series, only the Precision 5680 offers an OLED option.
2. What is the difference between ISV certified drivers and Game Ready drivers?
ISV drivers are tested and certified for stability by software companies like Autodesk and Dassault before release. Game Ready drivers are optimized for gaming and may cause display errors or crashes in CAD/BIM software when running heavy projects. If you use Revit, SolidWorks, or CATIA as your primary tools, ISV drivers significantly reduce risks.
3. Is the GeForce RTX 4060 more powerful than the RTX 2000 Ada?
In terms of raw benchmarks (3DMark, game FPS), the GeForce RTX 4060 is usually higher. However, in engineering software like Revit or SolidWorks, the RTX 2000 Ada's SPECviewperf score is often equal to or higher due to drivers specifically optimized for professional viewports. The choice depends on which software you use most.
4. Is the RAM on the Precision 5680 upgradable?
It depends on the configuration. Some SKUs use soldered LPDDR5, which cannot be replaced. Other SKUs use DDR5 SODIMM, which is upgradable. When purchasing, please ask for the specific configuration of the unit being sold to know for certain.
